| Place of Origin: | Jiangsu, China |
| اسم العلامة التجارية: | Nanyang |
| الأسعار: | CN¥7,683,432.13/sets 1-1 sets |
|---|---|
| Packaging Details: | Sea worthy packing |
| Supply Ability: | 200 Set/Sets per Year pipe mill line |
| Video outgoing-inspection: | Provided | Machinery Test Report: | Provided |
|---|---|---|---|
| Core Components: | PLC, Bearing, Gearbox, motor, Pump | Type: | Pipe Mill |
| Pipe Material: | Carbon steel | Application: | Energy Supply Pipe |
| Production Capacity: | 120t/h | Voltage: | 220V/380V/415V/440V |
| Power(w): | 1248000 | Dimension(L*W*H): | oem |
| Weight: | 52000 kg | Warranty: | one year |
| Key Selling Points: | Long Service Life | Diameter of welded tube: | 89-219mm |
| Wall Thickness of welded tube: | 2.5-8.0mm | Milling speed: | 12-35M/Min |
| Main motor power: | 220KW*2 | High frequency power: | 600KW |
| Annual output: | 80000t | Applicable Industries: | Building Material Shops, Manufacturing Plant, Construction works , Energy & Mining |
| Showroom Location: | None | Warranty of core components: | 1 Year |
| Condition: | New | Marketing Type: | Hot Product 2021 |
| النموذج | ZG219 |
| قطر الأنبوب المطاوئ | Φ89 ~ Φ219mm |
| سمك الحائط للأنبوب المطاوئ | δ2.5~8.0mm |
| سرعة الطحن | 12~35M/min |
| طاقة المحرك الرئيسي | 220 كيلوواط*2 |
| طاقة عالية التردد | 600 كيلوواط |
| الإنتاج السنوي | 80000 طن |
