| Place of Origin: | Jiangsu, China |
| اسم العلامة التجارية: | Nanyang |
| الأسعار: | CN¥9,421,400.02/sets 1-1 sets |
|---|---|
| Packaging Details: | Sea worthy packing |
| Supply Ability: | 200 Set/Sets per Year pipe mill line |
| Video outgoing-inspection: | Provided | Machinery Test Report: | Provided |
|---|---|---|---|
| Core Components: | PLC, Bearing, Gearbox, motor, Pump | Type: | Pipe Mill |
| Pipe Material: | Carbon steel | Application: | Energy Supply Pipe |
| Production Capacity: | / | Voltage: | 220V/380V/415V/440V |
| Power(w): | 1277000 | Dimension(L*W*H): | oem |
| Weight: | 52000 kg | Warranty: | one year |
| Key Selling Points: | Long Service Life | Diameter of welded tube: | 102-273mm |
| Wall Thickness of welded tube: | 2.5-10.0mm | Milling speed: | 10-30M/Min |
| Main motor power: | 132KW*2 | High frequency power: | 800KW |
| Annual output: | 98600t | Applicable Industries: | Building Material Shops, Manufacturing Plant, Construction works , Energy & Mining |
| Showroom Location: | None | Warranty of core components: | 1 Year |
| Condition: | New | Marketing Type: | Hot Product 2021 |
| الموديل | ZG273 |
| قطر الأنبوب الملحوم | Φ102~Φ273mm |
| سمك جدار الأنبوب الملحوم | δ2.5~10.0mm |
| سرعة الطحن | 10~30 متر/دقيقة |
| قدرة المحرك الرئيسي | 132KW*2 |
| طاقة التردد العالي | 800KW |
| الإنتاج السنوي | 98600 طن |
